喷头体型号

Body type

连接螺纹

Connecting thread

流量范围

Flow range

外径

O/D

清洗管径范围

Suitable i/d

range of tubes

长度

Length

备注

Remark

USR11

1/4-28 LH/RH

M7

10~36 l/min

11mm

14~22mm

40mm

Drilled orifices

USR13

1/4-28 LH/RH

1/16-27 NPT (Max.1035bar)

M7

11~44 l/min

13mm

15~25mm

37mm

Drilled orifices

USR17

1/4-28 LH/RH

1/16-27 NPT (Max.1035bar)

1/8 NPT (Max.1035bar)

3/8-24 LH/RH

1/8 BSPP

M8/M8X1

13~65 l/min

17mm

22~33mm

41mm

Drilled orifices

USR27A

3/8-24 LH/RH

1/8 BSPP

M10X1

1/8 NPT (Max .1035bar)

13~65 l/min

27mm

36~60mm

69mm

Drilled orifices

USR27B

3/8-24 LH/RH

1/8 BSPP

M10X1

1/8 NPT (Max .1035bar)

13~65 l/min

27mm

36~60mm

73mm

M3 Nozzles

USR32A

3/8-24 LH/RH

1/8 BSPP

M10X1

1/8 NPT (Max. 1035bar)

13~65 l/min

32mm

45~65mm

69mm

Drilled orifices

USR32B

3/8-24 LH/RH

1/8 BSPP

M10X1

1/8 NPT (Max. 1035bar)

13~65 l/min

32mm

45~65mm

73mm

M3 Nozzles
